Pneumatic Tractor Mounted 8T 300m Deep Hole Drilling Machine

Name: Pneumatic Tractor Mounted 8T 300m Deep Hole Drilling Machine
Brand: ShiTan
Price: 1 USD

Pneumatic Tractor Mounted 8T 300m Deep Hole Drilling Machine Manufactures

Brand Name : ShiTan

Model Number : ST-300

Certification : ISO

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, D/A, T/T, Western Union

Supply Ability : 2000Set/Year

Delivery Time : Within 7-12 days

Packaging Details : Standard export transportation package

Model : ST-300

Name : Pneumatic Borewell Machine

Voltage : 380V

Color : Red ,Yellow or OEM

Total weight : 8T

Usage : industrial and civil drilling and geothermal drilling

Power Type : Diesel

Max drilling depth : 300m

Drilling diameter : 105-300mm

Contact Now

ST-300 crawler borehole pneumatic deep borewell drilling rigs

1.Overview of ST-300 Pneumatic Drilling Rig

ST300 series deep(water) well-drilling rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.

The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

2.ST-350S Pneumatic Drilling Rig Parameter:

ST300 trailer mounted water well drilling rig
The weight	8T
Drilling diameter	105-300mm
Drilling depth	300m
One-time advance length	4m
Walking speed	2.5km/h
Climbing angles	Max.30°
Equipped capacitor	65-70KW
Using air pressure	1.7-3.0Mpa
Air consumption	17-30m³/min
Drill pipe diameter	φ50mmΦ76 mm φ89mm
Drill pipe length	1.5m 2.0m 3.0m
Rig lifting force	12T
Swing speed	45-70rpm
Swing torque	3500-5900N.m
Dimension	4m×1.9m×2.3m

3. Advantages of ST-300 pneumatic water well drilling rig:

Large Hole Diameter
Deep Drilling
High Penetration Rate, especially under pure rock condition
Flexible Movement
Wide Application Area

4.Application:

1. Civil engineering drilling
2. Geothermal drilling
3. Water well drilling
